4.1 TiO2 Pigments
Titanium dioxide is the most important white pigment used in coatings and plastics as well as other industrial fields, because it efficiently scatters visible light, thereby brings out high whiteness, brightness and excellent opacity when dispersed in coating vehicles, plastics or other systems. Tikon chemicals group supply titanium dioxide in two crystal structures - anatase and rutile.
A-100 is a cost-effective anatase titanium dioxide pigment, it is dry white powder and mainly recommended for interior wall paint, interior decorative paint, primer, paper, titanate-making, hand wash and soap. A-120 is a versatile anatase titanium dioxide pigment, it is fine dry white powder and has high brightness and excellent dispersion, widely used in waterborne and solvent coatings, plastics and rubbers, leather, paper making, printing ink, fiber & textile, hand wash and soap etc.
R-303 is a rutile titanium dioxide pigment，and its surface is coated with zirconia and alumina that prevent the pigment particles from crowding together in the systems，so it is easily dispersed and has high opacity. R-303 has bright whiteness with light blue shade，it is designed for the applications that require outstanding combination of gloss，dispersion，opacity and durability, and widely used in decorative paints, automotive coatings, powder coatings, marine paints，aerospace coatings，plastics and rubbers, printing inks, leather, paper-making，emulsion paints，etc.
R-306 is a rutile titanium dioxide pigment with alumina and organic surface treatment，it has bright neutral whiteness, high hiding power，excellent durability and dispersibility. It is designed primarily for plastic applications，and also used in solvent paints，powder coatings，marine paints，automotive coatings，aerospace coatings，printing inks and so on.
R-316 is a versatile rutile titanium dioxide pigment with zirconia and alumina surface treatment，and its particle size is carefully controlled in manufacturing process，thereby imparting bright whiteness, bluish undertone，high gloss，excellent opacity，outstanding dispersibility and super durability. It is widely used in solvent and waterborne systems for architectural and industrial coatings, decorative paints, automotive coatings, powder coatings, marine paints，aerospace coatings，plastics and rubbers, leather, fibers，printing inks，paper-making，etc.
R-318 is a rutile titanium dioxide pigment with alumina and organic surface treatment，designed to create clean bright whiteness，high opacity and high tint power，neutral blue undertone, outstanding durability and excellent dispersibility. It is specifically used in plastics，thin film，fiber and masterbatch. Besides，it is also used in solvent paints，automotive coatings，powder coatings，marine paints，aerospace coatings，printing inks and so on.
4.2 Carbon Black Pigments
Our Carbon Black products are environmentally -friendly and meet the standards of EU and REACH on environmental indicators，produced through partial combustion of hydrocarbons to meet rigorous specifications and deliver important functionality according to end-user performance requirements. The types of carbon black pigments are usually defined by their particle size and structure，and these properties of carbon black enable its unique characteristics that deliver critical value to end-users through a range of functionalities including color, UV protection , conductivity and so on.
TIK-900 series are high performance carbon black pigments designed for a variety of applications such as automotive coatings, industrial and architectural coatings, Decorative coatings, toners and printing inks, sealants, film and sheet, fibers, moldings, pipes and semi-conductive cables.
Item | Test Method | Unit | TIK-918 | TIK-920 | TIK-926 | TIK-933 | TIK-936 |
NSA | ASTM D6556 | m2 /g | 175±15 | 122±10 | 116±10 | 85±10 | 98±10 |
Oil Absorption | ASTM D2414 | cc /100g | 63±8 | 112±8 | 74±8 | 102±8 | 82±8 |
Tint Strength | ASTM D3265 | % | 130±8 | 114±8 | 112±8 | 106±8 | 108±8 |
Volatile | ASTM D1509 | % | ≤1.5 | ≤1.5 | ≤1.5 | ≤1.5 | ≤1.5 |
Mesh Residue,45μm | ASTM D1514 | % | ≤0.05 | ≤0.05 | ≤0.05 | ≤0.05 | ≤0.05 |
Ash | ASTM D1506 | % | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 |
TIK-800 series are specialty conductive carbon blacks, designed to achieve optimal conductive or electrostatic dissipative (ESD) performance, and to improve battery performance or in conductive primers for coatings applications, and in plastic to render normally resistive polymers electrically conductive, protecting materials and equipment against premature failure or damage due to electrostatic discharge.
Item | Test Method | Unit | TIK-806 | TIK-808 | TIK-812 | TIK-815 | TIK-824 |
NSA | ASTM D6556 | m2 /g | 40±6 | 70±6 | 80±6 | 78±6 | 65±6 |
Oil Absorption | ASTM D2414 | cc /100g | 123±8 | 128±8 | 126±8 | 75±8 | 105±8 |
Tint Strength | ASTM D3265 | % | 55±6 | 92±6 | 120±6 | 110±6 | 102±6 |
Volatile | ASTM D1509 | % | ≤1.5 | ≤1.5 | ≤1.5 | ≤1.5 | ≤1.5 |
Mesh Residue,45μm | ASTM D1514 | % | ≤0.02 | ≤0.02 | ≤0.02 | ≤0.02 | ≤0.02 |
Ash | ASTM D1506 | % | ≤0.3 | ≤0.3 | ≤0.3 | ≤0.3 | ≤0.3 |
4.3 Iron oxide pigments
1）Granular iron oxide pigment
It is effective-cost pigment as well as excellent durability , super heat resistance, good light fastness and chemical resistance. It is non-toxic, low heavy metal and environment friendly.
Application: widely used in exterior coatings, industrial coatings, marine coating，road-marking, concrete prefabricated components and building product materials.
CI Generic Name | CI Constitution No | Type | Fe oxide （%） | Oil absorption（cc/100g） | Residue on 45um (%) | Water sol. matter (%) | Moisture (%) | PH | Tinting strength (%) |
Pigment Red 101 | 77491 | 110 | ≥96 | 15-25 | ≤0.2 | ≤0.3 | ≤1.0 | 3-7 | 95-105 |
120 | ≥96 | 15-25 | ≤0.2 | ≤0.3 | ≤1.0 | 3-7 | 95-105 | ||
130 | ≥96 | 15-25 | ≤0.2 | ≤0.3 | ≤1.0 | 3-7 | 95-105 | ||
140 | ≥96 | 15-25 | ≤0.2 | ≤0.3 | ≤1.0 | 3-7 | 95-105 | ||
160 | ≥96 | 15-25 | ≤0.2 | ≤0.3 | ≤1.0 | 3-7 | 95-105 | ||
180 | ≥96 | 15-25 | ≤0.2 | ≤0.3 | ≤1.0 | 3-7 | 95-105 | ||
190 | ≥96 | 15-25 | ≤0.2 | ≤0.3 | ≤1.0 | 3-7 | 95-105 | ||
Pigment yellow 42 | 77492 | 311 | ≥86 | 25-35 | ≤0.3 | ≤0.3 | ≤1.0 | 3-7 | 95-105 |
313 | ≥86 | 25-35 | ≤0.3 | ≤0.3 | ≤1.0 | 3-7 | 95-105 | ||
586 | ≥86 | 25-35 | ≤0.3 | ≤0.3 | ≤1.0 | 3-7 | 95-105 | ||
910 | ≥86 | 25-35 | ≤0.3 | ≤0.3 | ≤1.0 | 3-7 | 95-105 | ||
920 | ≥86 | 25-35 | ≤0.3 | ≤0.3 | ≤1.0 | 3-7 | 95-105 | ||
Pigment black 11 | 77499 | 318 | ≥90 | 15-25 | ≤0.3 | ≤0.5 | ≤1.0 | 5-8 | 95-105 |
330 | ≥90 | 15-25 | ≤0.3 | ≤0.5 | ≤1.0 | 5-8 | 95-105 | ||
740 | ≥90 | 15-25 | ≤0.3 | ≤0.5 | ≤1.0 | 5-8 | 95-105 | ||
750 | ≥90 | 15-25 | ≤0.3 | ≤0.5 | ≤1.0 | 5-8 | 95-105 | ||
Iron oxide brown (Combination of CI. 77491,77492,77499) | 77491 77492 77499 | 610 | ≥88 | 20-30 | ≤0.3 | ≤0.5 | ≤1.0 | 4-7 | 95-105 |
660 | ≥88 | 20-30 | ≤0.3 | ≤0.5 | ≤1.0 | 4-7 | 95-105 | ||
663 | ≥88 | 20-30 | ≤0.3 | ≤0.5 | ≤1.0 | 4-7 | 95-105 | ||
686 | ≥88 | 20-30 | ≤0.3 | ≤0.5 | ≤1.0 | 4-7 | 95-105 | ||
841 | ≥88 | 20-30 | ≤0.3 | ≤0.5 | ≤1.0 | 4-7 | 95-105 | ||
Iron oxide orange (Combination of CI. 77491,77492) | 77491 77492 | 960 | ≥88 | 20-30 | ≤0.3 | ≤0.3 | ≤1.0 | 3-7 | 95-105 |
2040 | ≥88 | 20-30 | ≤0.3 | ≤0.3 | ≤1.0 | 3-7 | 95-105 |
2）Transparent iron oxide pigment
It is designed to provide a transparent color effect, as well as to enhance UV stability, durability and heat resistance.
Application：primarily for automotive coating and carpentry paint, also widely used in decorative paint, furniture paint, industrial coatings, inks, plastics, paper, leather and cosmetics.
Product | CI Generic Name | Type | Oil Absorption（cc/g） | Thermal Stability（℃） | Conductivity(us/cm) | Specific surface (m2/g) | PH |
Transparent iron oxide red | Pigment Red 101 | 817T | 40-50 | ≥300 | ≤1000 | 80-120 | 7-9 |
Transparent iron oxide yellow | Pigment yellow 42 | 916T | 40-50 | ≥180 | ≤1000 | 80-110 | 7-9 |
Transparent iron oxide brown | Mixture | 300T | 40-50 | ≥300 | ≤1000 | 80-120 | 7-9 |
Transparent iron oxide orange | Mixture | 416T | 40-50 | ≥180 | ≤1000 | 80-110 | 7-9 |
3）Micronized iron oxide pigment
Micronized iron oxide pigment has fine particle size, which is carefully controlled in manufacturing process，resulting in excellent opacity，high gloss，outstanding dispersibility and super durability. These pigments have a variety of applications as follows:
Coatings: including water-based interior and exterior coatings, powder coatings, solvent coatings, toy paint, decorative paint, furniture paint, electrophoretic paint and enamel.
Plastics and Elastomers：coloring thermosetting plastics and thermoplastics such as epoxy, alkyd, amino，automotive inner tubes and aircraft inner tubes，reinforcing elastomer and rubber.
Concrete colorant: used in various types of concrete prefabricated components and building product materials, directly mixed into cement for application. Architectural ceramics and glazed ceramics, such as face tiles, floor tiles, artificial marble, etc.
Product | CI Generic Name | Type | Fe oxide（%） | Oil absorption（cc/100g） | Residue on 45um (%) | Water sol. matter (%) | Moisture (%) | PH | Tinting strength (%) | Mean Particle Size (μm) |
Micronized iron oxide Red | Pigment Red 101 | 110M | ≥95 | 15-25 | ≤0.01 | ≤0.2 | ≤1.0 | 4-7 | 95-105 | ≤1.0 |
120M | ≥95 | 15-25 | ≤0.01 | ≤0.2 | ≤1.0 | 4-7 | 95-105 | ≤1.0 | ||
130M | ≥95 | 15-25 | ≤0.01 | ≤0.2 | ≤1.0 | 4-7 | 95-105 | ≤1.0 | ||
140M | ≥95 | 15-25 | ≤0.01 | ≤0.2 | ≤1.0 | 4-7 | 95-105 | ≤1.0 | ||
180M | ≥95 | 15-25 | ≤0.01 | ≤0.2 | ≤1.0 | 5-7 | 95-105 | ≤1.0 | ||
Micronized iron oxide Yellow | Pigment yellow 42 | 313M | ≥86 | 25-35 | ≤0.01 | ≤0.2 | ≤1.0 | 4-7 | 95-105 | ≤1.5 |
920M | ≥86 | 25-35 | ≤0.01 | ≤0.2 | ≤1.0 | 4-7 | 95-105 | ≤1.5 | ||
Micronized iron oxide Black | Pigment black 11 | 318M | ≥90 | 15-25 | ≤0.01 | ≤0.3 | ≤1.0 | 5-8 | 95-105 | ≤2.0 |
330M | ≥90 | 15-25 | ≤0.01 | ≤0.3 | ≤1.0 | 5-8 | 95-105 | ≤2.0 |
4.4 Complex metal oxide pigments
Complex metal oxide pigments are high performance inorganic pigments, which are environment friendly and non-toxic. They have high color intensity, strong hiding power, high UV reflectivity, good glossiness, high temperature resistance, excellent weather resistance, excellent color fastness and no migration.
Application: recommended for the plastic industry such as PE, PP, PVC, PA, PC, PS, HIPS, PMMA, ABS, SAN, PET, PUR and rubber, and coatings industry including automotive paint, industrial paint, powder coating, roll coating, architectural coating, marine coating, etc. Also widely used in glass, enamel, ceramic, ink, color paper and so on.
CI Generic Name | CI Constitution No | Chemical Type | Heat Resistance（℃） | Light fastness | Weather Resistance | Oil Absorption（cc/g） | pH | Mean Particle Size(μm) |
Pigment Brown 24 | 77310 | Cr/Sb/Ti oxide | ≥1000 | 8 | 5 | 10-25 | 6-9 | ≤1.0 |
Pigment Brown 29 | 77500 | Fe/ Cr oxide | ≥1000 | 8 | 5 | 10-25 | 6-9 | ≤2.0 |
Pigment Brown 33 | 77503 | Zn/Fe/ Cr oxide | ≥1000 | 8 | 5 | 10-25 | 6-9 | ≤1.5 |
Pigment Yellow 53 | 77788 | Ni/Sb/Ti oxide | ≥1000 | 8 | 5 | 10-25 | 6-9 | ≤2.0 |
Pigment Yellow 164 | 77899 | Mn/Sb/Ti oxide | ≥1000 | 8 | 5 | 10-25 | 6-9 | ≤1.0 |
Pigment Yellow 184 | 771740 | Bi/V/Mo oxide | ≥300 | 7-8 | 5 | 25-40 | 6-9 | ≤1.5 |
Pigment Blue 28 | 77346 | Co/Al oxide | ≥1200 | 8 | 5 | 20-40 | 6-9 | ≤2.0 |
Pigment Blue 36 | 77343 | Co/Cr/Al oxide | ≥500 | 8 | 5 | 10-28 | 6-9 | ≤1.0 |
Pigment Green 17 | 77288 | Cr oxide | ≥1000 | 8 | 5 | 10-25 | 6-9 | ≤1.5 |
Pigment Green 50 | 77377 | Co/Ni/Zn/Ti oxide | ≥1000 | 8 | 5 | 10-25 | 6-9 | ≤1.5 |
Pigment Black 28 | 77428 | Cu/Fe/ Cr oxide | ≥750 | 8 | 5 | 10-25 | 6-9 | ≤2.0 |
Pigment Black 30 | 77504 | Fe/ Cr/Ni oxide | ≥1000 | 8 | 5 | 10-25 | 6-9 | ≤1.5 |
